BD Diesel Xtrude Trans Cooler w/Fan 5.5in – SBX Performance High Quality

Description

Manufacturer Part # : 1300611

Market Description

• BDs High Performance CP3 (HPCP3) Injection Pump with up to a 72-percent increase in capacity / displacement delivers enough fuel to support up to 750hp while maintaining 24,000psi of rail pressure. The HPCP3 pump replaces the existing injection pump and simply bolts in place to produce up to 5.25 LPM versus the stock 3.05 LPM.That is right, all that fuel without going to a dual pump system – no extra pulleys, belts or pumps to install.BDs HPCP3 pumps are engineered with an enhanced metering unit and new design cam shaft with modified plungers and stroke. Plus, the HPCPS eliminates the off throttle fuel spikes common with stock pumps that can potentially damage injector nozzle tips when trying to produce more than 500hp. All of these modifications deliver long-term durability with consistent high fuel pressure supply on demand that provides efficient atomization resulting in more power, better combustion and lower EGTs. Designed for street, towing and race track applications, each HPCP3 injection pump is fully tested before leaving our facility.Chevy Duramax 6.6L and Dodge 6.7L engine applications coming soon!
• 22% more cooling over other designs

Product Description – Extended

Xtruded Auxiliary Transmission Oil Cooler; Incl. Fan; -10 JIC Male Connection;

Features and Benefits

• Large surface area to transfer heat for external air flow cooling
• 57 Percent Cooling Surface w/95 Percent Better Heat Dissipation
• Furnace brazed rails have been tested to 300psi of pressure
• Turbulent oil flow design promotes a more complete cooling
• Large 5/8-inch ports prevents inlet/outlet restriction
• 33,930 BTU/HR and in excess of 30,000 GVW!
• 80-watt, 10-inch, 800 CFM electric fan
• Motor is IP54 with 65% duty cycle
• 12 Month Or 12000 Mile Warranty
• 200 Micro Extruded passages
• Cooler Assembly Only
• Replacement Fan

Product Description – Long

• BD Xtrude Transmission Cooler with Fan -10 JIC Male Connection
• Xtruded Auxiliary Transmission Oil Cooler

Product Description – Short

• BD Diesel Xtrude Trans Cooler w/Fan 5.5in
• XTRUDED TRANS COOLER
• A/TOilCooler

Product Description – Invoice

XTRUDED TRANS COOLER SINGLE COOLER W/FAN

AAIA Part Type Description

Automatic Transmission Oil Cooler
